Disco Check Valve Typ RV110

Wafer Disco-Check Valve: Stainless Steel

The RV110 is also called a disco-check valve. The special feature of this valve is its four ground clips. The valve disc is connected with a spring, so that the RV110 closes automatically even at low-pressure rates or return flow, therefore an outlet flow is avoided. Disco-check valves are particularly suitable for clean liquids and gases. The RV110 is available in many material combinations and can be designed for the respective application. Please see our datasheet for detailed information. We offer check valves in a wide selection of various materials and designs. Please get in touch with our sales department to be advised on this issue comprehensively and freely.

Stainless steel disco check valve properties

Disco check valve type RV110-SSMFW (Art.-Nr.: 300-1140-xx)

• DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300
• Body: Stainless steel 1.4408 / 1.4581
• Disc: Stainless steel 1.4408 / 1.4581
• Spring: Stainless steel 1.4571
• Seat: metal
• With 4 grounding lugs

Disco check valve type RV110-SSEFW (Art.-Nr.: 300-1142-xx)

• DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300
• Body: Stainless steel 1.4408 / 1.4581
• Disc: Stainless steel 1.4408 / 1.4581
• Spring: Stainless steel 1.4571
• Seat: EPDM
• Temperature range: -40°C to +120°C
• With 4 grounding lugs

Disco check valve type RV110-CSMFW (Art.-Nr.: 300-1150-xx)

• DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300
• Body: cast steel 1.0619
• Disc: stainless steel 1.4408 / 1.4581
• Spring cross: stainless steel 1.4408 / 1.4581
• Spring: stainless steel 1.4571
• Seat: metal
• With 4 grounding lugs

Download “Check Valve RV110”
