Flanged Ends ASG4
The ATOMAC ASG4 sight glass offers clear visual inspection from either side, highly corrosion resistant PFA liners cover all internal parts and borosilicate glass, in accordance with DIN 7080 is utilized to withstand high temperatures, mechanical stress and corrosion. Optional available with PFA-conductive liner material.
Type
Sightglass
Sizes
DN25, DN50, DN80, 1", 2", 3"
Flange connection
PN10, ANSI 150, PN16
Face-to-face
DIN EN 558 Line 1
Body material
GGG40+PFA, GGG40+FEP
Pressure range
PN16
Lining/Coating
PFA, FEP
Connection
Flanges
