Knife Gate Valve
The FM200 is the most commonly used knife gate valve of FERGO Armaturen GmbH. Because of its cheaper price and multiple installation options, this flat gate valve is an allrounder for many different application areas. As a uni-directional knife gate valve it is ideal for handling liquids with solids, for example, sewage, but also for handling in the biogas sector. Optionally the fitting can be provided with a bonnet. This bonnet avoids the medium’s outlet into the environment and enables a smooth lining of the knife gate valve under water or in the ground. The bonnet is also recommended for high-pressure ratings, aggressive liquids and harmful gases.
The brilliant and simple construction of the body and seat guarantees a long, failure-free operation at a minimum amount of maintenance. The applications of the FM200 knife gate valve are the paper and pulp industry, power plant technology, water and sewage technology, chemical industry, food industry, bulk industry and many more. The different sizes, pressure stages, materials and drives are shown on the datasheet, which you can download on our website. You can also download the 3D model of the valve directly from our Fergo-Shop website. For special executions and additional requests, please contact our sales department.
Knife gate valve FM200 with GG25-body and handwheel
Knife gate valve type FM200-CS1ERW (Art.-Nr.: 270-1000-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: GG25
- Gate: SS304L (1.4306)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seal: EPDM
- Working temperature: -20°C to +120°C
- Actuator: handwheel, rising stem
Knife gate valve type FM200-CS1NRW (Art.-Nr.: 270-1001-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: GG25
- Gate: SS304L (1.4306)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./NBR/PTFE-Synt.
- Seal: NBR
- Working temperature: -20°C to +90°C
- Actuator: handwheel, rising stem
Knife gate valve type FM200-CS1MRW (Art.-Nr.: 270-1002-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: GG25
- Gate: SS304L (1.4306)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seal: Metal
- Working temperature: -20°C to +120°C
- Actuator: handwheel, rising stem
Knife gate valve FM200 with GG25-body and pneumatic actuator
Knife gate valve type FM200-CS1EDW (Art.-Nr.: 270-1008-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: GG25
- Gate: SS304L (1.4306)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seal: EPDM
- Working temperature: -20°C to +120°C
- Actuator: pneumatic double acting
Knife gate valve type FM200-CS1NDW (Art.-Nr.: 270-1011-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: GG25
- Gate: SS304L (1.4306)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./NBR/PTFE-Synt.
- Seal: NBR
- Working temperature: -20°C to +90°C
- Actuator: pneumatic double acting
Knife gate valve type FM200-CS1MDW (Art.-Nr.: 270-1003-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: GG25
- Gate: SS304L (1.4306)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seal: metal
- Working temperature: -20°C to +120°C
- Actuator: pneumatic double acting
Knife gate valve FM200 with stainless steel body and handwheel
Knife gate valve type FM200-SSERW (Art.-Nr.: 270-1005-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: CF8M (1.4408)
- Gate: SS316L (1.4404)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seal: EPDM
- Working temperature: -20°C to +120°C
- Actuator: handwheel rising stem
Knife gate valve type FM200-SSNRW (Art.-Nr.: 270-1015-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: CF8M (1.4408)
- Gate: SS316L (1.4404)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./NBR/PTFE-Synt.
- Seal: NBR
- Working temperature: -20°C to +90°C
- Actuator: handwheel rising stem
Knife gate valve type FM200-SSMRW (Art.-Nr.: 270-1009-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: CF8M (1.4408)
- Gate: SS316L (1.4404)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seat: metal
- Working temperature: -20°C to +120°C
- Actuator: handwheel rising stem
Knife gate valve FM200 with stainless steel body and pneumatic actuator
Knife gate valve type FM200-SSEDW (Art.-Nr.: 270-1006-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: CF8M (1.4408)
- Gate: SS316L (1.4404)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seal: EPDM
- Working temperature: -20°C to +120°C
- Actuator: pneumatic double acting
Knife gate valve type FM200-SSNDW (Art.-Nr.: 270-1017-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: CF8M (1.4408)
- Gate: SS316L (1.4404)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./NBR/PTFE-Synt.
- Seal: NBR
- Working temperature: -20°C to +90°C
- Actuator: pneumatic double acting
Knife gate valve type FM200-SSMDW (Art.-Nr.: 270-1007-xx)
- DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200
- Connection: Wafer flanged PN10
- Body: CF8M (1.4408)
- Gate: SS316L (1.4404)
- Stem: SS303 (1.4305)
- Packing: PTFE-Synt./EPDM/PTFE-Synt.
- Seal: Metal
- Working temperature: -20°C to +120°C
- Actuator: pneumatic double acting
Type
Knife Gate Valve
Operations
Handwheel rising Stem, Handwheel non-rising Stem, Chainwheel, Electric Actuator, Pneumatic double-acting, Pneumatic single-acting, Quick-closing Lever, Gearbox with Handwheel
Sizes
DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1100, DN1200
Flange connection
PN10, ANSI 150, PN16
Body material
GG25, GGG40, 1.4408, 1.4571
Gate plate
1.4301, 1.4408, 1.4571, Hardox
Packing gland
PTFE, Graphite, PTFE+NBR, PTFE+EPDM, PTFE+Viton
Sealing ring
NBR, EPDM, Silicon, Viton, PTFE, Flucast ABP, Metal
Pressure range
PN10
