Threaded Ends VA100

Our gate valve VA100 is suitable for domestic water services, heating and air-conditioning plants. The gate valve VA100 has female threads on both ends according to ISO228 (equivalent to DIN EN ISO 228 and BS EN ISO 228). Also available with NPT thread in the size 2½“ and larger. The body is made of brass, the red painted handwheel is made of steel. Maximum working temperature is 150°C in absence of steam.

Gate valve type VA100-MMMNI (Art.-Nr.: 201-1000-xx)
• 1/2″, 3/4″, 1″, 1 1/4″, 1 1/2″, 2″, 2 1/2″ 3″, 4″
• Threads ends acc. to ISO 228 [female/female]
• Body: brass CW617N
• Disc: brass CW617N
• Seat: metal to metal
• Nominal pressure: 16 bar/232psi
• Working temperature: 0°C bis 150°C in absence of steam
• Handle in steel

Download “Gate Valve VA100”
