Gate valve type VA210

Gate valve: handwheel or electric

The VA210 is a high-quality gate valve designed for a wide range of applications. The VA210 flanged gate valve is metal seated, available in stainless steel and bronze options, which provides a reliable seal and a long service life even under higher temperatures and harsh conditions. Equipped with a graphite gland packing, this wedge gate valve offers optimum tightness and minimises the risk of leakage.

The body and wedge of the VA210 wedge gate valve are made of high-quality EN-GJS-400-15 (GGG40) cast iron, which ensures high durability and longevity. The overall face-to-face length of the VA210 complies with the EN 558-1 standard, series 14 (F4), which enables easy integration into existing pipework systems.

Whether you are looking for a gate valve with handwheel or an electric gate valve, the VA210 fulfils all requirements while offering the flexibility to be smoothly integrated into various systems. We can gladly offer you the gate valve with electric rotary actuators such as AUMA and Bernard. The VA210 is delivered with a non-rising stem handwheel, which is ideal for installation where space is limited.

Gate valve type VA210-D2D2SNF (Art.Nr.: 201-2014-xx) DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN500, DN600

• Nominal pressure: PN10/16
• Body/Wedge: EN-GJS-400-15 (GGG40)
• Sealing ring: stainless steel 1.4021
• Gland packing: graphite
• Face to face length acc. EN 558-1, Row 14 (F4)
• Flanged ends acc. to EN 1092-2, PN10/16
• Max. working pressure: 16 bar
• Operation: handwheel, non rising stem

Gate valve type VA210-D2D2BNF (Art.-Nr.: 201-2015-xx) DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250, DN300, DN350, DN400, DN500, DN600

• Nominal pressure: PN10/16
• Body/Wedge: EN-GJS-400-15 (GGG40)
• Sealing ring: bronze
• Gland packing: graphite
• Face to face length acc. EN 558-1, Row 14 (F4)
• Flanged ends acc. to EN 1092-2, PN10/16
• Max. working pressure: 16 bar
• Operation: handwheel, non rising stem

Download “Gate Valve VA210 Handwheel”
